Description
Product features
*Axis design,while stranding! Greatly improve production efficiency
*LCD backlit display,modern mobile operating prin ciple. People out of the digital set operation cumbersome vertigo fatigue andother shortcomings;
*The motor shaft directly,without loss of drive torque,zero maintenance,brushless,electromang netic brakes,belts and other mechanical wear
*A sound industrial grade protection circuit design, the data that has been set with perfect data protection, and data can be permanently stored
*Different segments can set different winding direction,speed having positive and megative counting function,minimal noise,high speed constant torque;
*Start fast,high speed, direct braking at high speed,high efficiency.For tension to prevent starting 0-9 kinds of ad hoc methods to choose from a slow start when a thin line around the system, you can set different segments were different slow start mode;
*The system has finished winding production statistics, automatic segment feature also optionally woud dan;
*Scope : electronic wire, winding wire, braided isolated lines, computer lines
Specification
| Power source | AC 110/220 50/60HZ single phase |
| Motor | Stepless motor 100w |
| Can be twisted path | 32AWG-16AWG |
| Operational capacity | A variety of specifications of electronic wire twisted(braided) |
| Operation | Single-action pedal |
| Volume | 220w*240l*240h(mm) |
| Weight | 10kg |
Wire Twisting Machine Samples
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
